MANET Routing Protocols using ns3

#AODV #OLSR #MANETs #DSDV #DSR

Download the Code here:
https://drive.google.com/open?id=1OkVOsifjN9UfQjPGvfR7OuS-x_GBRgCV

Check the Video for Detailed instruction and how to use the plots, graphs and source code.


Comparison of MANET routing Protocols 1. AODV
2. DSDV
3. DSR
4. OLSR
using NS3 (Network Simulator 3)
B.Tech, M.Tech, PhD...
1. Reactive Vs Proactive routing
2. PErformance comparison of MANET protocols
3. AODV Vs DSDV Comparison

https://www.nsnam.com and also at my channel.

What Version: ns-3.29
My Ubunut OS is: Ubuntu 18.04

This file we are going to use for our simulation:
/home/networks/ns-allinone-3.29/ns-3.29/examples/routing/manet-routing-compare.cc

Once you under stand the code, now lets run this example

Step 1: Copy the above file in to ~ns-3.29/scratch/ folder

Step 2: Understand this code.
Step 3: Run this code
Open the terminal, Go to ns-3.29 and run the following command

$] ./waf --run scratch/manet-routing-compare

enable the following header file

#include "ns3/flo…
8 comments
Read more

OpenFlow in NS3

Installation of OpenFlow in NS3 is a simple task  and here is the method to do that.

NS3 version: ns-3.24.1 and ns-3.25

Assumption: You should have installed #ns3 already in your machine.

#OpenFlow is a software helpful for Simulating Software Defined Networks (#SDN).

There are some packages needed to enable OpenFlow. Download these packages and try the installation later.

$] sudo apt-get install libboost-all-dev libxml2 libxml2-dev

Go to the ~ns-allinone-3.24.1/ns-3.24.1 folder and give this command

$] hg clone http://code.nsnam.org/openflow
(if the above command does not work, the give this command)
$] sudo apt-get install mercurial

$] cd openflow
$] ./waf configure
$] ./waf build
(if the build failed in the above steps, please give your comments)

$] cd ..
$] ./waf configure --enable-examples --enable-tests --with-openflow=path/to/openflow

In my case
$] ./waf configure --enable-examples --enable-tests --with-openflow=openflow

After you run the above command, you should get the following scre…
3 comments
Read more
